Description
Feature:
• The use of electrostatic powder coating, plating handles with more attractive appearance and resistance to
• Compact design, flexibility and effort moving
• Low equipment costs, high operating efficiency
• Easy to use, gentle women, senior citizens and to facilitate the operation of the same light
Specifications:
|
Model |
LT-150F |
LT-300F |
LT-350D |
LT-500 |
LT-500D |
LT-800 |
LT-1000 |
|
Load Capacity (kg) |
150 |
300 |
350 |
500 |
500 |
800 |
1000 |
|
A |
Max. Lifting Height (MM) |
750 |
900 |
1300 |
960 |
1300 |
1000 |
1000 |
|
|
Min. Table Height (MM) |
250 |
320 |
350 |
325 |
350 |
410 |
410 |
|
B |
Table Length (MM) |
700 |
810 |
910 |
910 |
910 |
1000 |
1000 |
|
C |
Table Width (MM) |
450 |
500 |
520 |
520 |
520 |
513 |
6513 |
|
D |
Overall Length (MM) |
875 |
1020 |
1098 |
1100 |
1098 |
1320 |
1320 |
|
E |
Handle Height (MM) |
825 |
960 |
960 |
960 |
960 |
980 |
980 |
|
Overall Width (MM) |
450 |
500 |
520 |
520 |
520 |
575 |
575 |
|
Wheels Size (MM) |
100x32 |
127x38 |
127x38 |
127x38 |
127x38 |
150x40 |
150x40 |
|
No.OF Brake |
1 |
1 |
1 |
1 |
1 |
2 |
2 |
|
Service Weight (kg) |
34 |
72 |
95 |
85 |
100 |
110 |
11 |
