Description
Standard Features:
• Wide and suitable flat loading area for entry into the vehicle
• Easy installation and easy collection
• Specially produced for heavy use conditions
• Time and cost savings with its maintenance-free structure
• Easy to move with standard forklifts with forklift skids on the ramp
• Safe connection with the vehicle with the security chain
• Ability to work in all weather conditions with galvanized gratings
• Designed for intensive use
• With handrails on both sides for extra safety
• With its foldable structure, space can be saved with a minimum of space when not in use.
• 2 heavy-duty wheels
• Front and rear tongue can be controlled with a single manual hand pump.
Technicial Specifications:
|
Model |
|
MLD.08 |
MLD.10 |
MLD.12 |
|
Capacity |
Kg |
8000 |
10000 |
12000 |
|
Ramp Length |
(L) mm |
10500 |
10500 |
10500 |
|
Ramp Width |
(W) mm |
2150 |
2150 |
2150 |
|
Climbing Section |
(La) mm |
5000 |
5000 |
5000 |
|
Straight Part |
(Lb) mm |
2500 |
2500 |
2500 |
|
Front Tongue Length |
(Da) mm |
700 |
700 |
700 |
|
Back Tongue Length |
(Db) mm |
2000 |
2000 |
2000 |
|
Front Tongue Width |
(Dw) mm |
950 |
950 |
950 |
|
Min / Max Height |
(Ha / Hb) mm |
1060/1650 |
1060/1650 |
1060/1650 |
|
Lift Type |
|
Manual |
Manual |
Manual |
